How to change the temperature control spool of single cold faucet
Method one:
1. Close the total water valve first
2. Then put a red and blue mark of about 8 mm on the handle of the faucet and buckle it down.
3. Use a flat-blade screwdriver to loosen the set screw counterclockwise and remove the handle.
4. Use a spanner wrench to disassemble the temperature control spool of the faucet, open the upper part of the gland with a wrench, and remove the ceramic valve inside.
Method 2:
1. Close the total water valve first
2. Use a screwdriver to insert the handle under the faucet, squatting from side to side, and licking it on one side, gradually come and use it evenly, so that the temperature-controlled spool can be removed.
Method three:
1. Close the total water valve first
2. Unscrew the blue cover on the right handle
3. Loosen the screw inside with a Phillips screwdriver and take off the handle to reveal the temperature-controlled spool.
4. Use a spanner wrench to unscrew the thermostatic spool
How to replace the new temperature control spool
1. After removing the temperature control spool, you will see a blue rubber band on the bottom of the temperature control spool. It is customary to have a red rubber on the bottom of the left thermostated spool and a blue eraser on the right.
2, so when changing the temperature control spool on the right side, use the blue rubber temperature control valve core, after the temperature control valve core is installed, the handle is inserted, adjust the direction of the hand wheel, the handle is turned off when the two sides are closed. The direction of the person standing is boiling water.
3. Install the screw and cover the blue cap on the right side, so replace the new temperature control spool.
How to change the temperature control spool of hot and cold water tap
1, preparatory work
a. The temperature control spool is broken. First buy a new temperature control spool. The new temperature control spool must match your faucet.
b. According to the screws of your own faucet, prepare a word or Phillips screwdriver, perhaps an hex wrench, and then prepare a needle-nosed pliers and a knife.
Note: Under normal circumstances, which brand of faucet to buy will go to this brand of shop to buy a thermostatic valve core, which can basically be bought.
2, remove the hot water button
a. Before replacing the thermostatic spool, first find the water switch of the faucet, then turn it off to avoid water spray when it is replaced.
b. Then find hot and cold; ‘’Lincoln, the button for the water might be a plastic cap, and sneak it down with a small blade so that you can see the screws inside.
3, remove the handle
a. After opening the hot and cold water button, look at the shape of the screw, whether it is a word or a cross flower, maybe a hexagonal screw b. Then decide which screwdriver, perhaps an Allen key. Remove the screw in the hole with a screwdriver and remove the handle of the faucet.
4, unloading the temperature control spool
a. After removing the handle, you can see the temperature-controlled spool inside. Some temperature-controlled spools have a fixed outer cover on the outside, and the cover can be removed.
b. Then you can see the clip of the fixed temperature control spool. There are generally four claws on the clip. The two claws are stuck on both sides of the needle-nosed pliers, and then the clock can be removed by rotating clockwise.
5, installation
a. After removing the card, the bad temperature-controlled spool can be removed.
b. Then install the new thermostatic spool, reverse the previous process, and reinstall the other components.
c. After installing the faucet handle, punch the water source valve and try to leak water. After no problem, lock the handle and install the hot and cold plastic cap.
